The DASUTWC500NF from Pulse Electronics is a flat patch RF antenna covering 784 MHz, 1.9475 GHz, 2.5 GHz LTE and Wi-Fi, 608–960 MHz, 1.695–2.2 GHz and 2.3–2.7 GHz, with 4 dBi, 6 dBi and 6 dBi gain and an N-type female panel mount.

The ANT4050JB01BGN25A from Pulse Electronics is a GNSS+L2+L stacked ceramic patch RF antenna operating at 1.176 GHz, 1.2276 GHz, 1.561 GHz, 1.575 GHz and 1.602 GHz, with 3 dBic, 0.57 dBic, 2.96 dBic, 3.69 dBic and 1.71 dBic gain, and an IPEX connector mount.

The DASUTCCR500NF from Pulse Electronics is a flat patch Wi-Fi antenna with 784 MHz, 1.947 GHz and 2.5 GHz, 608–960 MHz, 1.695–2.2 GHz and 2.3–2.7 GHz bands, 7 dBi, 7 dBi and 5 dBi gain, and an N-type female panel mount.

The ACTPAT154-01-IP from Inventek Systems is a 1.575 GHz GPS ceramic patch RF antenna covering 1.573–1.583 GHz with 0.5 dBi gain, a U.FL (UMCC) / IPEX MHF1 connector and surface mounting.

The ATIGGBL22580-100 from YIC is a GNSS ceramic patch RF antenna for BeiDou, Galileo, GLONASS, GNSS and GPS at 1.227, 1.561, 1.575, 1.602 GHz, bands 1.217–1.237, 1.559–1.563, 1.574–1.576, 1.594–1.61 GHz, gains 2.11, 2.19, -0.3, -0.2, 0.47, 0.7, 3.18, 3.09 dBi, IPEX magnetic.

The PDM24499-FNF from TE Connectivity Laird is a 2.4 GHz and 5.4 GHz Wi-Fi flat panel RF antenna covering 2.4–2.5 GHz and 4.9–5.95 GHz, with 9.6 dB gain, an N-type female connector and a chassis mount.

The ANT-8/9-FPC-UFL-100 from Linx Technologies Inc. is a flat patch RF antenna for 868 MHz and 915 MHz ISM, LoRaWAN, LPWA and 5G, covering 862–876 MHz and 902–930 MHz with -3.2 dBi and -3 dBi gain, a U.FL (UMCC), IPEX MHF1 connector and adhesive mount, rated below 960 MHz.

The PSQ24495-91NF from TE Connectivity Laird is a 2.4 GHz and 5.4 GHz WiBro flat panel RF antenna covering 2.4–2.5 GHz and 4.9–6 GHz, with 7.7 dB gain, an N-type female connector and a bracket mount.

The ANT-5GFPCB6958-UFL from RF Solutions is a 5G flexible adhesive PCB flat patch RF antenna for 5G, GPS and GSM, with frequencies 700 MHz, 960 MHz, 1.8 GHz, 2.7 GHz, 3.5 GHz and 3.8 GHz, gains of 8 dBi and 10 dBi, and a U.FL (UMCC) or IPEX MHF1 adhesive connection.

The ANT-5GMFPC1-UFL-100 from Linx Technologies Inc. is a flat patch RF antenna for 5G, cellular and LTE at 2.3, 2.496, 3.3, 3.55, 3.7 and 4.4 GHz, covering 2.3–2.4, 2.496–2.69, 3.3–3.8, 3.55–3.7, 3.7–4.2 and 4.4–5 GHz with 3, 4.7, 4.8, 4.8, 5.9 and 6.7 dBi gain, a U.FL (UMCC), IPEX MHF1 connector and adhesive mount.

The ANT-GFPCB2452-UFL from RF Solutions is a GSM flat patch antenna for 830 MHz and 2.25 GHz, covering 700–960 MHz and 1.8–2.7 GHz, with 4 dBi gain and an adhesive mount.

The ANT-W63-FPC-SH50UF from Linx Technologies Inc. is a flat patch antenna (25x20 mm, 50 mm, U.FL/UMCC, IPEX MHF1, adhesive) for 802.11b/g/ac/ax, Bluetooth, ISM, U-NII, Zigbee, Wi-Fi 4/5/6/6E. It covers 2.45 GHz, 5.5225 GHz, 6.5375 GHz, 2.4–2.5 GHz, 5.15–5.895 GHz and 5.95–7.125 GHz at 4.7, 7.8 and 8.5 dBi.

The ACTPAT182-01-IP from Inventek Systems is a 1.575 GHz GPS ceramic patch RF antenna covering 1.573–1.583 GHz with 1 dBic gain, a U.FL (UMCC) and IPEX MHF1 connection, in a surface-mount package.

The 3951D-HR-10CM-UFL from PCTEL, Inc. is a 1.575 GHz GPS ceramic patch RF antenna covering 1.565–1.585 GHz, with -2dBic and 3dBic gain and a U.FL surface-mount connector.

The CRJKS0009-LNA-LM5X3000SMA from NimbeLink, LLC is a magnetic-mount GPS ceramic patch GNSS antenna at 1.5845 GHz, covering 1.559–1.61 GHz with 23 dB gain and an SMA connector.

The ANT-GNFPC-SHL1100M4 from Linx Technologies Inc. is a GNSS L1 flat patch RF antenna for Beidou, Galileo, GLONASS and GPS at 1.561 GHz, 1.575 GHz, 1.601 GHz and 1.602 GHz, with 2.6–3.2 dBi gain, 100 mm length, an MHF4 connector and adhesive mount.

The GPSF.36.7.A.30 from Taoglas Limited is a single-feed stacked patch antenna for GPS.

The YCGS004AA from Quectel is an SMD ceramic patch RF antenna for BeiDou, Galileo, GNSS and GPS at 1.575 GHz, covering 1.573–1.576 GHz, with -6.3 dBi gain and solder surface mount.

The ANT-5GW-FPC-V100UF from Linx Technologies Inc. is a 120X20 flat patch RF antenna, 100 mm long, with an MHF1, U.FL connector and adhesive mounting for 2G, 3G, 4G, 5G and LTE. Frequencies: 657.5 MHz, 750.5 MHz, 842.5 MHz, 1.175 GHz, 1.593 GHz, 1.947 GHz, 2.495 GHz, 3.75 GHz and 4.7 GHz. Ranges: 617–698 MHz, 698–803 MHz, 791–894 MHz, 832 MHz–1.518 GHz, 1.525–1.661 GHz, 1.695–2.2 GHz, 2.3–2.69 GHz, 3.3–4.2 GHz and 4.4–5 GHz. Gains: 4.6, 6.6, 7.9, 7.9, 6.2, 4.9, 4.1, 6.3 and 7.9 dBi.

The ANT-5GW-FPC-LH200M4 from Linx Technologies Inc. is a 5G FPC flat patch RF antenna measuring 120 x 20 and 200 mm, with an MHF4 connector and adhesive mount, for 2G, 3G, 4G, 5G and LTE. Frequencies are 657.5 MHz, 750.5 MHz, 842.5 MHz, 1.175 GHz, 1.593 GHz, 1.947 GHz, 2.495 GHz, 3.75 GHz and 4.7 GHz, ranges are 617–698 MHz, 698–803 MHz, 791–894 MHz, 832–1.518 GHz, 1.525–1.661 GHz, 1.695–2.2 GHz, 2.3–2.69 GHz, 3.3–4.2 GHz and 4.4–5 GHz, and gains are 5 dBi, 5 dBi, 5.5 dBi, 6 dBi, 5.2 dBi, 5.1 dBi, 7 dBi, 6.2 dBi and 6.8 dBi.

The 2042860001 from Molex is a ceramic patch RF antenna for Beidou, GLONASS and GPS with 5.5 dBi gain; solder SMD and solder through-hole mounting are both specified.

The 2108854-1 from TE Connectivity AMP Connectors is an active GNSS flat patch antenna with MHF feed, 100 mm length, for L1+G1 & L2 at 1.225 GHz and 1.5845 GHz, covering 1.194–1.255 GHz and 1.559–1.61 GHz, with 28.2–32.8 dBic and 29.5–35.2 dBic gain, an RP-SMA male connector and adhesive mounting.

The YG0005AA from Quectel is a GPS ceramic patch RF antenna for 1.575 GHz and 1.6 GHz, covering 1.597–1.603 GHz, with solder adhesive mounting.

The 1002649 from KYOCERA AVX is an embedded ceramic patch antenna for Beidou, Galileo, GLONASS, GNSS and GPS at 1.561, 1.575 and 1.603 GHz, covering 1.559–1.563, 1.559–1.591 and 1.593–1.61 GHz, with 5, 5.5, 5.5 and 5.5 dBi gain, solder adhesive and through-hole mounting.

The SAM-M10Q-00B from u-blox is an M10 GNSS RF receiver module with patch antenna for Galileo, GLONASS and GPS at 1.575 GHz and 1.602 GHz, with -165 dBm, 400 kbps and on-board patch.

The APARC2504A-SG3 from Abracon LLC is an active ceramic patch RF antenna for GNSS, GPS, GLONASS and BeiDou, covering 1.558–1.61 GHz with 2 dBi gain and solder surface mounting; its inputs also cite 1.584 GHz and Bluetooth, ISM, Wi-Fi and Zigbee.

The PEWAN112-15NF from Pasternack is a WR112 gain horn RF antenna covering 7.05–10 GHz with 15 dBi gain.

The 3951D-HR-50CM-MMCX from PCTEL, Inc. is a 1.575 GHz GPS ceramic patch RF antenna covering 1.565–1.585 GHz, with -2dBic and 3dBic gain and an MMCX surface-mount connector.

The ANT-20264IB93 from Adam Tech is a ceramic patch antenna for Beidou, Galileo, GLONASS and GPS at 1.575 GHz, 1.602 GHz and 1.608 GHz, with 5.2 dBi, 4.3 dBi and 4 dBi gain and solder adhesive mounting.

The PEWAN187-15NF from Pasternack is a WR187 gain horn RF antenna for 3.95 GHz to 5.85 GHz with 4.9 GHz center frequency and 15 dBi gain, with an N-type female connector and waveguide flange mount.

The ANT-5GW-FPC-V200UF from Linx Technologies Inc. is a 120X20 flat patch RF antenna, 200 mm long, with an MHF1, U.FL connector and adhesive mounting for 2G, 3G, 4G, 5G and LTE. Frequencies: 657.5 MHz, 750.5 MHz, 842.5 MHz, 1.175 GHz, 1.593 GHz, 1.947 GHz, 2.495 GHz, 3.75 GHz and 4.7 GHz. Ranges: 617–698 MHz, 698–803 MHz, 791–894 MHz, 832 MHz–1.518 GHz, 1.525–1.661 GHz, 1.695–2.2 GHz, 2.3–2.69 GHz, 3.3–4.2 GHz and 4.4–5 GHz. Gains: 4.6, 6.6, 7.9, 7.9, 6.2, 4.9, 4.1, 6.3 and 7.9 dBi.

The 2042870200 from Molex is a 433 MHz ISM flat patch RF antenna with 0.5 dBi gain, a U.FL (UMCC) connector and IPEX MHF1 adhesive mounting.

The ECHO34/0.1M/UFL/S/S/17 from Siretta Ltd is an embedded ceramic patch antenna measuring 25 x 25 x 4 mm for 2.398–2.402 GHz, covering 2.4 GHz Bluetooth, Wi-Fi and Zigbee™, with 2 dBi gain, a U.FL (UMCC) / IPEX MHF1 connector and surface mounting.

The 1461860200 from Molex is a 200 mm flat patch RF antenna for 1.561 GHz, 1.575 GHz, 1.602 GHz, 2.4 GHz, 5 GHz BeiDou, GLONASS, WiMax, WLAN and Wi-Fi, covering 1.575–1.602 GHz, 2.4–2.483 GHz, 5.15–5.85 GHz and 3–6 GHz with 2.7, 3.5 and 4.2 dBi gain, U.FL (UMCC) and IPEX MHF1 connectors, adhesive mount.

The APAM1568YE15V2.0 from Abracon LLC is a 1.575 GHz GPS ceramic patch RF antenna covering 1.573–1.578 GHz with 1.5 dBic gain, a U.FL (UMCC) or IPEX MHF1 connector and surface mounting.

The 1357D-15CM-UFL from PCTEL, Inc. is a 1.575 GHz GPS/GNSS ceramic patch RF antenna covering 1.565–1.585 GHz, with 0.5 dBic gain, a U.FL connector and surface-mount design.
