Search results for “POSCAP TPF”

TPD4F202YFUR from Texas Instruments is a FILTER RC(PI) 100 OHM/15PF SMD

TPS70345MPWPREP from Texas Instruments is a Integrated Circuit Enhanced product, dual-output low-dropout voltage regulator with power-up sequencing - Linear & low-dropout (LDO) regulators. The TPS70345 is designed to provide a complete power management solution for Texas Instruments DSP, processor power, ASIC, FPGA, and digital applications where dual output voltage regulators are required. Easy programmability of the sequencing function makes this family ideal for any Texas Instruments DSP applications with power sequencing requirement. Differentiated features, such as accuracy, fast transient response, SVS supervisory circuit (power on reset), manual reset inputs, and enable function, provide a complete system solution. The TPS70345 voltage regulator offers low dropout voltage and dual outputs with power up sequence control, which is designed primarily for DSP applications. This device has a low noise output performance without using any added filter bypass capacitors and are designed to have a fast transient response and be stable with 47 µF low ESR capacitors. This device has a fixed output voltage 3.3 V/1.2 V. Regulator 1 can support up to 1 A, and regulator 2 can support up to 2 A. Separate voltage inputs allow the designer to configure the source power. Because the PMOS pass element behaves as a low-value resistor, the dropout voltage is very low (typically 160 mV on regulator 1) and is directly proportional to the output current. Additionally, since the PMOS pass element is a voltage-driven device, the quiescent current is low and independent of output loading (maximum of 250 µA over the full range of output current). This LDO family also features a sleep mode; applying a high signal to EN (enable) shuts down both regulators, reducing the input current to 1 µA at T J = 25°C. The device is enabled when the EN pin is connected to a low-level input voltage. The output voltages of the two regulators are sensed at the V SENSE1 and V SENSE2 pins respectively. The input signal at the SEQ pin controls the power-up sequence of the two regulators. When the device is enabled and the SEQ terminal is pulled high or left open, V OUT2 turns on first and V OUT1 remains off until V OUT2 reaches approximately 83% of its regulated output voltage. At that time V OUT1 is turned on. If V OUT2 is pulled below 83% (i.e. overload condition) of its regulated voltage, V OUT1 will be turned off. Pulling the SEQ terminal low reverses the power-up order and V OUT1 is turned on first. The SEQ pin is connected to an internal pullup current source. For each regulator, there is an internal discharge transistor to discharge the output capacitor when the regulator is turned off (disabled). The PG1 pin reports the voltage conditions at V OUT1. The PG1 pin can be used to implement a SVS (power on reset) for the circuitry supplied by regulator 1. The TPS70345 features a RESET (SVS, POR, or power on reset). RESET is an active low, open drain output and requires a pullup resistor for normal operation. When pulled up, RESET goes to a high impedance state (i.e. logic high) after a 120 ms delay when all three of the following conditions are met. First, V IN1 must be above the undervoltage condition. Second, the manual reset (MR) pin must be in a high impedance state. Third, V OUT2 must be above approximately 95% of its regulated voltage. To monitor V OUT1, the PG1 output pin can be connected to MR1 or MR2. RESET can be used to drive power on reset or a low-battery indicator. If RESET is not used, it can be left floating. Internal bias voltages are powered by VIN1 and require 2.7 V for full functionality. Each regulator input has an undervoltage lockout circuit that prevents each output from turning on until the respective input reaches 2.5 V.

TPK-6A from OptiFuse is a UL Class M Fuse, Time Delay 6A

TPS60111PWPG4 from Texas Instruments is a Integrated Circuit 3 cell to regulated 5V, 150-mA low noise charge pump - DC/DC converters. The TPS60111 step-up, regulated charge pump generates a 5-V ±4% output voltage from a 2.7-V to 5.4-V input voltage (three alkaline, NiCd, or NiMH batteries; or, one lithium or lithium ion battery). Output current is 150 mA from a 3-V input. Only four external capacitors are needed to build a complete low-noise dc/dc converter. The push-pull operating mode of two single-ended charge pumps assures the low output voltage ripple as current is continuously transferred to the output. From a 3-V input, the TPS60111 can start into full load with loads as low as 33 Ω. The TPS60111 features either constant frequency mode to minimize noise and output voltage ripple or the power-saving pulse-skip mode to extend battery life at light loads. The TPS60111 switching frequency is 300 kHz. The logic shutdown function reduces the supply current to 1-µA (max) and disconnects the load from the input. Special current-control circuitry prevents excessive current from being drawn from the battery during start-up. This dc/dc converter requires no inductors and has low EMI. It is available in the small 20-pin TSSOP PowerPAD™ package (PWP).

TPLH-2R7/3000SL60138 from Tecate Group is a CAP 3000F 2.7V CHASSIS MOUNT

TPK-R-6A from OptiFuse is a UL CLASS M FUSE, TIME DELAY 6A

TPCP8004(TE85L,F) from Toshiba Semiconductor and Storage is a MOSFET N-CH 30V 8.3A PS-8

TPLH-2R7/1200SL60X74 from Tecate Group is a CAP 1200F 2.7V CHASSIS MOUNT

TPK-3A from OptiFuse is a UL CLASS M FUSE, TIME DELAY 3A

TPLH-2R7/2000SL60102 from Tecate Group is a CAP 2000F 2.7V CHASSIS MOUNT

TPK-6.3A from OptiFuse is a UL Class M Fuse, Time Delay 6.3A

TPS75301QPWPREP from Texas Instruments is a Integrated Circuit Enhanced product, fast transient response 1.5-A low-dropout voltage regular - Linear & low-dropout (LDO) regulators. The TPS753xxQ and TPS751xxQ are low dropout regulators with integrated power-on reset and power-good (PG) functions respectively. These devices are capable of supplying 1.5 A of output current with a dropout of 160 mV (TPS75133Q, TPS75333Q). Quiescent current is 75 µA at full load and drops down to 1 µA when the device is disabled. TPS751xxQ and TPS753xxQ are designed to have fast transient response for larger load current changes. Because the PMOS device behaves as a low-value resistor, the dropout voltage is very low (typically 160 mV at an output current of 1.5 A for the TPS75x33Q) and is directly proportional to the output current. Additionally, since the PMOS pass element is a voltage-driven device, the quiescent current is very low and independent of output loading (typically 75 µA over the full range of output current, 1 mA to 1.5 A). These two key specifications yield a significant improvement in operating life for battery-powered systems. The device is enabled when EN is connected to a low level voltage. This LDO family also features a sleep mode; applying a TTL high signal to EN (enable) shuts down the regulator, reducing the quiescent current to less than 1µA at T J = 25°C. For the TPS751xxQ, the power-good terminal (PG) is an active high, open drain output, which can be used to implement a power-on reset or a low-battery indicator. The RESET (SVS, POR, or power on reset) output of the TPS753xxQ initiates a reset in microcomputer and microprocessor systems in the event of an undervoltage condition. An internal comparator in the TPS753xxQ monitors the output voltage of the regulator to detect an undervoltage condition on the regulated output voltage. When the output reaches 95% of its regulated voltage, RESET goes to a high-impedance state after a 100-ms delay. RESET goes to a logic-low state when the regulated output voltage is pulled below 95% (i.e., over load condition) of its regulated voltage. The TPS751xxQ or TPS753xxQ is offered in 1.5-V, 1.8-V, 2.5-V and 3.3-V fixed-voltage versions and in an adjustable version (programmable over the range of 1.5 V to 5 V). Output voltage tolerance is specified as a maximum of 2% over line, load, and temperature ranges. The TPS751xxQ and TPS753xxQ families are available in 20-pin TSSOP (PWP) packages.

TPK-7A from OptiFuse is a UL CLASS M FUSE, TIME DELAY 7A

TPCP8103-H(TE85LFM from Toshiba Semiconductor and Storage is a MOSFET P-CH 40V 4.8A PS-8

TPK-10A from OptiFuse is a UL CLASS M FUSE, TIME DELAY 10A

TPS2383APMG4 from Texas Instruments is a IC OCTAL POWER MANAGER 64LQFP

TPCP8005-H(TE85L,F from Toshiba Semiconductor and Storage is a MOSFET N-CH 30V 11A PS-8

TPS7201QPW from Texas Instruments is a IC REG LIN POS ADJ 250MA 8TSSOP

TPS54680MPWPEP from Texas Instruments is a IC REG CONV 1OUT 28HTSSOP

TPS54613MPWPREP from Texas Instruments is a IC REG BUCK 1.5V 6A 28HTSSOP

TPK-1.5A from OptiFuse is a UL Class M Fuse, Time Delay 1.5A

TPK-630mA from OptiFuse is a UL Class M Fuse, Time Delay 630m

TPK-R-3.15A from OptiFuse is a UL Class CC Fuse, Time Delay 3.1

TPK-1A from OptiFuse is a UL CLASS M FUSE, TIME DELAY 1A

TPS2384PAPR from Texas Instruments is a IC POE CNTRL 4 CHANNEL 64HTQFP

TPLH-3R0/38WR12X46 from Tecate Group is a CAP 38F 3.0V T/H

TPK-30A from OptiFuse is a UL CLASS M FUSE, TIME DELAY 30A

TPS2384PAP from Texas Instruments is a IC POE CNTRL 4 CHANNEL 64HTQFP

POS-104UL w/o Cable from Moxa is a 4 Port UPCI Board, w/o Cable, RS

TPS60110PWPG4 from Texas Instruments is a Integrated Circuit 3 cell to regulated 5V, 300-mA low noise charge pump - DC/DC converters. The TPS60110 step-up, regulated charge pump generates a 5-V ±4% output voltage from a 2.7-V to 5.4-V input voltage (three alkaline, NiCd, or NiMH batteries; or, one lithium or lithium ion battery). Output current is 300 mA from a 3-V input. Only four external capacitors are needed to build a complete low-noise dc/dc converter. The push-pull operating mode of two single-ended charge pumps assures the low output voltage ripple as current is continuously transferred to the output. From a 3-V input, the TPS60110 can start into full load with loads as low as 16 Ω. The TPS60110 features either constant frequency mode to minimize noise and output voltage ripple or the power-saving pulse-skip mode to extend battery life at light loads. The TPS60110 switching frequency is 300 kHz. The logic shutdown function reduces the supply current to 1-µA (max) and disconnects the load from the input. Special current-control circuitry prevents excessive current from being drawn from the battery during start-up. This dc/dc converter requires no inductors and has low EMI. It is available in the small 20-pin TSSOP PowerPAD™ package (PWP).

TPS62112MRSAREP from Texas Instruments is a IC REG BUCK 5V 1.5A 16QFN

TSB14AA1TPFB from Texas Instruments is a IC BACKPLANE PHY 3.3V 48-TQFP

ISPPAC-POWR604-01TN44I from Lattice Semiconductor Corporation is a IC ISP POWER MGR ANLG/LOG 44TQFP

TPS2384APAP from Texas Instruments is a IC POE CNTRL 4 CHANNEL 64HTQFP

TPK-2.5A from OptiFuse is a UL Class M Fuse, Time Delay 2.5A

TPS2383BPMRG4 from Texas Instruments is a IC POE CNTRL 8 CHANNEL 64LQFP

TPK-4A from OptiFuse is a UL CLASS M FUSE, TIME DELAY 4A

25TQC22MYFT from Panasonic Electronic Components is a POLY TANT UL CAP 22UF 25V 2917
