Search results for “patch antenna”

The ANT-915-CPA from Linx Technologies Inc. is a 915 MHz ISM and RFID ceramic patch RF antenna covering 909 MHz to 921 MHz, with 1.5 dBi gain and pin adhesive mounting.

The JLTD1176-1575S25-18P4-2X from JC Antenna is a two-layer ceramic patch RF antenna at 1.176 GHz and 1.575 GHz, covering 1.173–1.179 GHz and 1.572–1.578 GHz, in a pin surface-mount design.

The JLT1575S10P4X from JC Antenna is a ceramic patch RF antenna at 1.575 GHz, covering 1.572–1.578 GHz with -12 dBi gain, in a pin surface-mount design.

The TQ0143AA0000 from TST is a ceramic patch RF antenna at 1.224 GHz and 1.574 GHz.

The JLT1575S25N4X from JC Antenna is a ceramic patch RF antenna at 1.585 GHz, covering 1.56–1.61 GHz with 2 dBi gain, in a pin surface-mount design.

The JLTD1248-1563S48-36P5-3A from JC Antenna is a two-layer ceramic patch RF antenna at 1.248 GHz and 1.563 GHz, covering 1.245–1.251 GHz and 1.558–1.568 GHz, in a pin surface-mount design.

The YCGO004AA from Quectel is a passive GNSS and GPS ceramic patch RF antenna at 1.582 GHz, covering 1.559–1.606 GHz, with an IPEX connector, adhesive mounting and a 10×10 size.

The YG0046AA from Quectel is an 18*18 ceramic patch RF antenna for BeiDou, Galileo, GNSS and GPS at 1.561 GHz and 1.575 GHz, covering 1.559–1.563 GHz and 1.573–1.577 GHz, with surface mount.

The SZK-C-0M04 from Synzen is an 868 MHz ISM flat patch RF antenna with an 886 MHz designation, covering 863–870 MHz with 1.21 dBi gain. It uses a U.FL (UMCC) and IPEX MHF4 connector with an adhesive mount.

The YG0038AA from Quectel is a 13*13 ceramic patch RF antenna for GNSS and GPS at 1.582 GHz, covering 1.559–1.606 GHz, with adhesive mount.

The JTT1575S20P4X from JC Antenna is a ceramic patch RF antenna at 1.575 GHz, covering 1.572–1.578 GHz with 2 dBi gain, in a pin surface-mount design.

The YCGA002AA from Quectel is a GNSS and GPS ceramic patch RF antenna at 1.5825 GHz, covering 1.559–1.606 GHz, with pin mount and surface-mount termination and a 1212 size.

The W3920B0100 from Pulse Electronics is a 5.4 GHz Wi-Fi flat patch RF antenna covering 4.9–5.925 GHz with 3 dBi gain, a U.FL (UMCC) / IPEX MHF1 connector and adhesive mount.

The H4700BZ3RCSFPM from Antenna Technologies Limited Company is a 4.7 GHz hemi patch antenna covering 4.4–5 GHz, with 6 dBi gain, an SMA female connector and panel mount.

The JLT1575S18P2X from JC Antenna is a ceramic patch RF antenna at 1.575 GHz, covering 1.572–1.578 GHz with -3.5 dBi gain, in a pin surface-mount design.

The YCGO010AA from Quectel is an active ceramic patch RF antenna for GNSS and GPS at 1.582 GHz, covering 1.559–1.606 GHz, with an 18×18 size, IPEX connector and adhesive mounting.

The H4700RCCBSESF3I from Antenna Technologies Limited Company is a 4700 MHz (4.7 GHz) hemi patch RF antenna covering 4.4–5 GHz with 9 dBi gain, an SMA female connector and panel mounting.

The YG0015AA from Quectel is an active GNSS ceramic patch RF antenna at 1.588 GHz, covering 1.575–1.602 GHz with 0.47 dBi gain, a 25×25 size, IPEX MHF connector and adhesive mounting.

The JTT1575S25P2X from JC Antenna is a ceramic patch RF antenna at 1.575 GHz, covering 1.572–1.578 GHz with 0 dBi gain, in a pin surface-mount design.

The APAKC2506A-SG3 from Abracon LLC is a ceramic patch RF antenna for Beidou, Galileo, GLONASS, GNSS and GPS at 1.561 GHz, 1.575 GHz and 1.602 GHz, covering 1.555–1.615 GHz with -1.5 dBi, -1 dBi and -2.5 dBi gain, IPEX connector, surface mount.

The APAE915R2540ABDB1-T from Abracon LLC is a GPS ceramic patch RF antenna at 915 MHz, covering 915–929 MHz with 4.5 dBic gain, a pin connection and adhesive mounting.

The JLT1575S12P2X from JC Antenna is a ceramic patch RF antenna at 1.575 GHz, covering 1.572–1.578 GHz with -5 dBi gain, in a pin surface-mount design.

The APAKM2507S-SGL5 from Abracon LLC is a stacked ceramic patch GNSS/GPS antenna for 1.176 GHz and 1.575 GHz, covering 1.175–1.177 GHz and 1.574–1.576 GHz with -3 dBi and 4 dBi gain and solder through-hole mounting.

The JLT1575S25P6X from JC Antenna is a ceramic patch RF antenna at 1.575 GHz, covering 1.572–1.578 GHz with 3.5 dBi gain, in a pin surface-mount design.

The JLT1575S1606P4X from JC Antenna is a ceramic patch RF antenna at 1.616 GHz and 2.492 GHz, covering 1.613–1.619 GHz and 2.489–2.495 GHz, in a pin surface-mount design.

The AN_GSM_108 from Maswell Communication Tech. is a Maswell 4G/3G slim patch antenna.

The 3961D-HR from PCTEL, Inc. is an adhesive-mount ceramic patch GNSS and GPS antenna at 1.575 GHz, covering 1.565–1.585 GHz with 3 dBic and -2 dBic gain.

The APAM1348YD13V2.0 from Abracon LLC is a 1.575 GHz GPS ceramic patch RF antenna covering 1.573–1.577 GHz with 1 dBic gain, a U.FL (UMCC) / IPEX MHF1 connector and surface mount.

The JTT1596S25P4X from JC Antenna is a ceramic patch RF antenna at 1.596 GHz, covering 1.593–1.599 GHz with 5 dBi gain, in a pin surface-mount design.

The APAM1068JL01V2.0 from Abracon LLC is a 1.575 GHz GPS ceramic patch RF antenna covering 1.574–1.576 GHz with -2 dBic gain, with U.FL (UMCC) and IPEX MHF1 connections in a surface-mount design.

The APARM1504-SG3 from Abracon LLC is a multiband ceramic patch RF antenna for Beidou, Galileo, GLONASS, GNSS and GPS at 1.561, 1.575 and 1.602 GHz, covering 1.561–1.602 GHz with -3 dBi, -4.5 dBi and 0.8 dBi gain and a solder through-hole mount.

The DASUTCC500MD from Pulse Electronics is a flat patch antenna for 700 MHz, 850 MHz, 900 MHz, 1.8 GHz, 1.9 GHz, 2.1 GHz, 2.4 GHz and 2.6 GHz LTE and Wi-Fi. It covers 608–960 MHz, 1.695–2.2 GHz and 2.3–2.7 GHz with 7 dBi, 7 dBi and 5 dBi gain and a Mini-DIN female panel-mount connector.

The JTT1575S35P4X from JC Antenna is a ceramic patch RF antenna at 1.575 GHz, covering 1.572–1.578 GHz with 2 dBi gain, in a pin surface-mount design.

The APARM2504-SG3 from Abracon LLC is a multiband ceramic patch RF antenna for Beidou, Galileo, GLONASS, GNSS and GPS at 1.561 GHz, 1.575 GHz and 1.602 GHz, covering 1.561–1.602 GHz with 2.5 dBi, 1.5 dBi and 3.5 dBi gain, for solder through-hole mounting.

The APAMPGJ-141 from Abracon LLC is a ceramic patch RF antenna for GLONASS and GPS at 1.575 GHz and 1.602 GHz, covering 1.575–1.61 GHz with 3 dBic gain, with U.FL (UMCC) and IPEX MHF1 connectors, surface mount.

The W3315B0100 from Pulse Electronics is an adhesive flat patch RF antenna for Bluetooth, WLAN and Zigbee at 2.45 GHz and 5.4 GHz, covering 2.4–2.5 GHz and 4.9–5.925 GHz with 2 dBi and 5 dBi gains and an IPEX MHF-A13 connector.

The JLT868S50P9X from JC Antenna is a ceramic patch RF antenna at 866.5 MHz, covering 863.5–869.5 MHz, in a pin surface-mount design.

The JLTD1616-2492S33-25P6-2.5X from JC Antenna is a two-layer ceramic patch RF antenna at 1.616 GHz and 2.492 GHz, covering 1.613–1.619 GHz and 2.489–2.495 GHz, in a pin surface-mount design.

The ANT-GSMGPSPCB from RF Solutions is a general-purpose ceramic patch RF antenna for 892 MHz, 1.575 GHz and 1.9 GHz, covering 824–960 MHz, 1.56–1.58 GHz and 1.71–1.99 GHz with 28 dB gain, U.FL (UMCC) and IPEX MHF1 surface-mount connection.
