The PEWAN102-15SM from Pasternack is a WR102 gain horn RF antenna covering 7–11 GHz with 15 dBi gain.

The PEWAN229-10NF from Pasternack is a WR229 gain horn RF antenna for 3.3 GHz to 4.9 GHz with 4.1 GHz center frequency and 10 dBi gain, with an N-type female connector and waveguide flange mount.

The 1004259 from Ethertronics/AVX is an active ceramic patch antenna for GPS and GLONASS at 1.575 GHz and 1.602 GHz, with 1.5 dBic gain, an IPEX MHF connector, surface mounting and the 25X6 designation.

The PE51OM1044 from Pasternack is a straight whip omni antenna for 2.5 GHz and 2.6 GHz, covering 2.5–2.7 GHz with 12 dBi gain, an N connector and a pole mount.

The PE51FP1005-4 from Pasternack is a panel RF antenna for 915 MHz GSM, ISM, LPWAN, LoRA and WLAN use, covering 902–928 MHz with 8 dBi gain, an SMA male connector and wall mount.

The PEANGPS1002 from Pasternack is a dome GNSS antenna for Galileo, GLONASS, GNSS and GPS, with 1.232 GHz and 1.57 GHz center frequencies, 1.164–1.3 GHz and 1.525–1.615 GHz bands, 41 dBi and 42 dBi gain, and a TNC female screw mount.

The 1357D from PCTEL, Inc. is a surface-mount ceramic patch RF antenna for 1.575 GHz GNSS and GPS, covering 1.565–1.585 GHz with 0.5 dBic gain and an H.FL connector.

The ANT-W63-FPC-SH200M4 from Linx Technologies Inc. is a flat patch RF antenna for 2.45 GHz, 5.5225 GHz and 6.5375 GHz (802.11b/g/ac/ax, Bluetooth, ISM, U-NII, Wi-Fi 4/5/6/6E, Zigbee), with 2.4–2.5 GHz, 5.15–5.895 GHz and 5.95–7.125 GHz ranges, 4.7, 7.8 and 8.5 dBi gain, an IPEX MHF4 connector and adhesive mount.

The 3951D-HR-24IN-HFL from PCTEL, Inc. is a GPS ceramic patch RF antenna at 1.575 GHz, covering 1.565–1.585 GHz with -2 dBic and 3 dBic gain, with H.FL connector for surface mounting.

The PSQ24495-91RSM from TE Connectivity Laird is a 2.4 GHz and 5.4 GHz Wi-Fi flat panel RF antenna covering 2.4–2.5 GHz and 4.9–6 GHz, with 7.7 dB gain, an RP-SMA connector and a bracket mount.

The CFSA69383P-30NF from TE Connectivity Laird is a flat panel antenna for GSM, LTE and WiMax™ at 829 MHz, 1.45 GHz and 2.75 GHz, covering 698–960 MHz, 1.35–1.55 GHz and 1.69–3.8 GHz, with 5.8 dBi gain, an N-type female connector and panel mount.

The PEWAN090-10ELNF from Pasternack is a 10.3 GHz general-purpose WR42 horn RF antenna for 8.2–12.4 GHz with 10 dBi gain, an N-type female connector and a waveguide mount.

The ANT-W63RPC1-50 from Linx Technologies Inc. is a rigid patch RF antenna for 802.11, 802.15.4, Bluetooth, U-NII, Wi-Fi 4/5/6/6E and Zigbee, covering 2.4–2.485 GHz, 5.15–5.85 GHz and 5.925–7.125 GHz with 3.7 dBi, 6.1 dBi and 5.9 dBi gain, with solder and adhesive mounting.

The H2M1W031129900 from Unictron Technologies Corporation is an NB40DG GLONASS and GPS (L1+L5) ceramic patch RF antenna at 1.176 GHz, 1.575 GHz and 1.602 GHz, with 2.7 dBi, 4.8 dBi and 3.9 dB gain, an IPEX connector and adhesive mounting.

The ANT-W63-FPC-LV50M4 from Linx Technologies Inc. is a flat patch antenna for 802.11b/g, Bluetooth, Wi-Fi, WLAN and Zigbee, at 2.45 GHz, 5.522 GHz and 6.537 GHz, ranges of 2.4–2.5 GHz, 5.15–5.895 GHz and 5.95–7.125 GHz, 4.8, 6.3 and 7.4 dBi gain, 45X7 size, 50 mm, MHF4 connector and adhesive mounting.

The GPS-14987 from SparkFun Electronics is a GPS/GNSS embedded ceramic patch RF antenna for 1.586 GHz Beidou, GLONASS, GNSS and GPS, covering 1.558–1.615 GHz with 4 dB gain, a 1M SMA connector and surface mounting.

The AFAG4330-SG3 from Abracon LLC is a flat patch RF antenna for Beidou, Galileo, GLONASS, GNSS and GPS at 1.561 GHz, 1.575 GHz and 1.602 GHz, covering 1.55–1.62 GHz with 2 dBi gain, an IPEX connector and an adhesive mount.

The PE51YA1015 from Pasternack is an HD Yagi antenna rated 10 dBi and 10.5 dBi for 400–435 MHz and 435–470 MHz, with 417.5 MHz and 452.5 MHz center frequencies for CDMA and LoRa, with an N-type female connector and bracket mount.

The PE51MP1005 from Pasternack is a 2 dBi general-purpose straight whip antenna for 380–520 MHz with an NMO magnetic mount, operating at 450 MHz.

The PEWAN062-10NM from Pasternack is a 15.2 GHz general-purpose horn RF antenna with 10 dBi gain covering 12.4–18 GHz, with an N-type male connector and waveguide mount.

The 1357D-20CM-SMB from PCTEL, Inc. is a 1.575 GHz GPS and GNSS ceramic patch RF antenna covering 1.565–1.585 GHz, with 0.5 dBic gain, an SMB connector and surface mounting.

The 3961D-7IN-RPSMAF from PCTEL, Inc. is a 1.575 GHz GPS ceramic patch RF antenna covering 1.565–1.585 GHz, with -2 dBic and 3 dBic gain, an RP-SMA female connector and surface mount.

The GGBSFTP.45.9.A.08 from Taoglas Limited is a SING ceramic patch antenna for 1.176 GHz, 1.227 GHz and 1.575 GHz (Beidou, Galileo, GLONASS, GPS), with -0.8 dBi, 1.1 dBi and 2.5 dBi gain, in a pin adhesive mount.

The ANT-W63-FPC-SH100M4 from Linx Technologies Inc. is a flat patch antenna (25x20, 100 mm, IPEX MHF4, adhesive) for 802.11b/g/-c/ax, Bluetooth, ISM, U-NII, Wi-Fi, Zigbee. It covers 2.45 GHz, 5.5225 GHz, 6.5375 GHz, 2.4–2.5 GHz, 5.15–5.895 GHz and 5.95–7.125 GHz at 4.7, 7.8 and 8.5 dBi.

The 3951D-HR-50CM-HFL from PCTEL, Inc. is a 1.575 GHz GPS ceramic patch RF antenna covering 1.565–1.585 GHz, with -2dBic and 3dBic gain and an H.FL surface-mount connector.

The ANT-GSMGPSPUKS from RF Solutions is a GPS/GSM puck antenna for 850 MHz, 900 MHz, 1.575 GHz, 1.8 GHz, 1.9 GHz and 2.6 GHz, covering 824–960 MHz, 1.57–1.58 GHz, 1.71–2.17 GHz and 2.6–2.7 GHz, with 2 dB and 30 dB values, (2) SMA male connectors and panel mounting.

The PE51OM1039 from Pasternack is an omni whip antenna for 617–960 MHz and 1.71–2.7 GHz with 6 dBi gain and an N female bracket mount, operating at 788.5 MHz and 2.205 GHz for 5G and LTE.

The 3951D-HR-LHCP-15CM-UFL from PCTEL, Inc. is a 1.575 GHz GPS ceramic patch RF antenna covering 1.565–1.585 GHz, with -2dBic and 3dBic gain and a U.FL surface-mount connector.

The ANT-W63RPC1-UFL-100 from Linx Technologies Inc. is a rigid patch RF antenna for 802.11, 802.15.4, Bluetooth, U-NII, Wi-Fi 4/5/6/6E and Zigbee, covering 2.4–2.485 GHz, 5.15–5.85 GHz and 5.925–7.125 GHz with 3.7 dBi, 6.1 dBi and 5.9 dBi gain, a U.FL (UMCC), IPEX MHF1 connector and adhesive mount.

The APAM2764YK0175 from Abracon LLC is a 1.575 GHz GPS ceramic patch RF antenna covering 1.573–1.578 GHz with 2.5 dBic gain and a U.FL (UMCC) or IPEX MHF1 surface-mount connector.

The YG0030AA from Quectel is a GPS ceramic patch RF antenna for 1.176 GHz and 1.575 GHz, with -0.9 dBi and 3.05 dBi gain, an IPEX MHF1 connector and surface-mount mounting.

The PEWAN102-10SM from Pasternack is a WR102 gain horn RF antenna covering 7–11 GHz with 10 dBi gain.

The PE51OM1046 from Pasternack is a straight whip omni antenna for 3.5 GHz, covering 3.3–3.8 GHz with 10 dBi gain, an N connector and a pole mount.

The PEWAN075-15NF from Pasternack is a WR75 gain horn RF antenna covering 10–15 GHz with 15 dBi gain.

The ANT-W63-FPC-LV150M4 from Linx Technologies Inc. is a flat patch antenna for 802.11b/g, Bluetooth, Wi-Fi, WLAN and Zigbee, at 2.45 GHz, 5.522 GHz and 6.537 GHz, ranges of 2.4–2.5 GHz, 5.15–5.895 GHz and 5.95–7.125 GHz, 4.8, 6.3 and 7.4 dBi gain, 45X7 size, 150 mm, MHF4 connector and adhesive mounting.

The 3951D-HR-77CM-N9 from PCTEL, Inc. is a 1.575 GHz GPS ceramic patch RF antenna covering 1.565–1.585 GHz, with -2dBic and 3dBic gain and an N-type surface-mount connector.

The GWSFTP.50.3.A.08 from Taoglas Limited is a 50 mm single-feed ceramic patch RF antenna for GPS and Wi-Fi at 1.575 GHz and 2.45 GHz, covering 1.574–1.576 GHz and 2.4–2.5 GHz with 1.6 dBi and 0.1 dBi gain, a pin connection and adhesive mount.

The ANT-W63RPC1-UFL-200 from Linx Technologies Inc. is a rigid patch RF antenna for 802.11, 802.15.4, Bluetooth, U-NII, Wi-Fi 4/5/6/6E and Zigbee, covering 2.4–2.485 GHz, 5.15–5.85 GHz and 5.925–7.125 GHz with 3.7 dBi, 6.1 dBi and 5.9 dBi gain, a U.FL (UMCC), IPEX MHF1 connector and adhesive mount.

The FXP75.07.0045B from Taoglas Limited is a 2.4 GHz Bluetooth flat patch RF antenna covering 2.4–2.5 GHz with 2.5 dBi gain, a U.FL (UMCC) / IPEX MHF1 connector and adhesive mount.

The CCAS-SB-7/800 from STI-CO Industries is a covert flat patch RF antenna system with BW 136, covering 760 MHz to 896 MHz with 828 MHz center, offering BNC, N-type, PL, SMA, TNC and UHF connectors with an adhesive mount.

The PE51MP1004 from Pasternack is a 3 dBi general-purpose straight whip antenna for 144–174 MHz with an NMO magnetic mount, operating at 159 MHz.

The PEWAN075-20NF from Pasternack is a WR75 gain horn RF antenna at 12.5 GHz, covering 10–15 GHz with 20 dBi gain, an N female connector and waveguide mounting.
