Search results for “74CB”

The 74CB3T1G125DBVRG4 from Texas Instruments is a bus switch with a 1 x 1:1 configuration in an SOT-23-5 package.

74CB3Q3306ADCURG4 from Texas Instruments is a Integrated Circuit 3.3-V, 1:1 (SPST), 2-channel FET bus switch (active low) - Protocol & bus switches & muxes. The SN74CB3Q3306A device is a high-bandwidth FET bus switch using a charge pump to elevate the gate voltage of the pass transistor, providing a low and flat ON-state resistance (ron). The low and flat ON-state resistance allows for minimal propagation delay and supports rail-to-rail switching on the data input/output (I/O) ports. The device also features low data I/O capacitance to minimize capacitive loading and signal distortion on the data bus. Specifically designed to support high-bandwidth applications, the SN74CB3Q3306A device provides an optimized interface option appropriate for broadband communications, networking, and data-intensive computing systems. The SN74CB3Q3306A device is organized as two 1-bit switches with separate output-enable (1 OE, 2 OE) inputs. It can be used as two 1-bit bus switches or as one 2-bit bus switch. When OE is low, the associated 1-bit bus switch is ON and the A port is connected to the B port, allowing bidirectional data flow between ports. When OE is high, the associated 1-bit bus switch is OFF, and a high-impedance state exists between the A and B ports. The SN74CB3Q3306A device is fully specified for partial-power-down applications using Ioff. The Ioff circuitry prevents damaging current backflow through the device when it is powered down. The device has isolation during power off. To confirm the high-impedance state during power up or power down, OE must be tied to VCC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.

The 74CB3T1G125DCKRG4 from Texas Instruments is a 1 x 1:1 bus switch in an SC-70-5 package.

The 74CB3T16210DGGRG4 from Texas Instruments is a bus switch Integrated Circuit with 10 switches in a 1:1 configuration, in a 48-TSSOP package.

The 74CB3T1G125DBVRE4 from Texas Instruments is a bus switch with a 1 x 1:1 configuration, in a SOT-23-5 package.

The 74CB3Q16244DGGRG4 from Texas Instruments is a bus switch Integrated Circuit with a 1 x 4:1 configuration, supplied in a 48-TSSOP package.

74CB3Q3306ADCURE4 from Texas Instruments is a Integrated Circuit 3.3-V, 1:1 (SPST), 2-channel FET bus switch (active low) - Protocol & bus switches & muxes. The SN74CB3Q3306A device is a high-bandwidth FET bus switch using a charge pump to elevate the gate voltage of the pass transistor, providing a low and flat ON-state resistance (ron). The low and flat ON-state resistance allows for minimal propagation delay and supports rail-to-rail switching on the data input/output (I/O) ports. The device also features low data I/O capacitance to minimize capacitive loading and signal distortion on the data bus. Specifically designed to support high-bandwidth applications, the SN74CB3Q3306A device provides an optimized interface option appropriate for broadband communications, networking, and data-intensive computing systems. The SN74CB3Q3306A device is organized as two 1-bit switches with separate output-enable (1 OE, 2 OE) inputs. It can be used as two 1-bit bus switches or as one 2-bit bus switch. When OE is low, the associated 1-bit bus switch is ON and the A port is connected to the B port, allowing bidirectional data flow between ports. When OE is high, the associated 1-bit bus switch is OFF, and a high-impedance state exists between the A and B ports. The SN74CB3Q3306A device is fully specified for partial-power-down applications using Ioff. The Ioff circuitry prevents damaging current backflow through the device when it is powered down. The device has isolation during power off. To confirm the high-impedance state during power up or power down, OE must be tied to VCC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.

The 74CB3Q3245RGYRG4 from Texas Instruments is a bus switch Integrated Circuit with 8 switches in a 1:1 configuration, in a 20-VQFN (3.5x4.5) package.

The 74CB3Q3244DBQRE4 from Texas Instruments is a bus switch Integrated Circuit with 4 switches in a 1:1 configuration, in a 20-SSOP package.

74CB3T3306DCURG4 from Texas Instruments is a Integrated Circuit 3.3-V, 1:1 (SPST), 2-channel FET bus switch with level shifter - Protocol & bus switches & muxes. The SN74CB3T3306 device is a high-speed TTL-compatible FET bus switch with low ON-state resistance (r on), allowing for minimal propagation delay. The device fully supports mixed-mode signal operation on all data I/O ports by providing voltage translation that tracks V CC. The SN74CB3T3306 device supports systems using 5-V TTL, 3.3-V LVTTL, and 2.5-V CMOS switching standards, as well as user-defined switching levels.

74CB3Q3305DCURG4 from Texas Instruments is a Integrated Circuit 3.3-V, 1:1 (SPST), 2-channel FET bus switch (active high) - Protocol & bus switches & muxes. The SN74CB3Q3305 device is a high-bandwidth FET bus switch using a charge pump to elevate the gate voltage of the pass transistor, providing a low and flat ON-state resistance (ron). The low and flat ON-state resistance allows for minimal propagation delay and supports switching input voltage beyond the supply on the data input/output (I/O) ports. The device also features low data I/O capacitance to minimize capacitive loading and signal distortion on the data bus. Specifically designed to support high-bandwidth applications, the SN74CB3Q3305 device provides an optimized interface option designed for broadband communications, networking, and data-intensive computing systems. This device is fully specified for partial-power-down applications using Ioff. The Ioff circuitry prevents damaging current backflow through the device when it is powered down. The device has isolation during power off. To ensure the high-impedance state during power up or power down, OE must be tied to GND through a pulldown resistor; the minimum value of the resistor is determined by the current-sourcing capability of the driver.

The 74CB3T3245DGVRE4 from Texas Instruments is an 8-bit FET bus switch with an 8 x 1:1 configuration in a 20-TVSOP package.

The 74CB3T3384DBQRG4 from Texas Instruments is a bus switch Integrated Circuit with 5 x 1:1 channels, in a 24-SSOP package.

The 74CB3T3383DBQRG4 from Texas Instruments is a bus FET exchange switch configured as 5 x 2:2 in a 24-SSOP package.

The 74CB3T3383DBQRE4 from Texas Instruments is a bus FET exchange switch configured as 5 x 2:2 in a 24-SSOP package.

The 74CB3Q3257RGYRG4 from Texas Instruments is a multiplexer/demultiplexer with 4 x 2:1 channels in a 16-VQFN (4x3.5) package.

The 74CB3Q3257PW-Q100J from Nexperia USA Inc. is a multiplexer/demultiplexer with a 4 x 2:1 configuration, in a 16-TSSOP package.

The 74CBTD1G125DCKRG4 from Texas Instruments is a 1 x 1:1 bus switch Integrated Circuit in an SC-70-5 package.

The 74CB3Q3257PWJ from Nexperia USA Inc. is a 4 x 2:1 multiplexer/demultiplexer Integrated Circuit in a 16-TSSOP package.

The 74CB3Q3253PWJ from Nexperia USA Inc. is a multiplexer/demultiplexer Integrated Circuit with a 2 x 4:1 configuration, in a 16-TSSOP package.

The 74CB3Q3257BQX from Nexperia USA Inc. is a multiplexer/demultiplexer Integrated Circuit with a 4 x 2:1 configuration, in a 16-DHVQFN (2.5x3.5) package.

The 74CB3Q3253BQX from Nexperia USA Inc. is a multiplexer/demultiplexer Integrated Circuit with a 2 x 4:1 configuration, in a 16-DHVQFN (2.5x3.5) package.

The 74CBT1G125DCKRG4 from Texas Instruments is a 1 x 1:1 bus switch Integrated Circuit in an SC-70-5 package.

The 74CBTLV1G125CRE4 from Texas Instruments is a 1 x 1:1 bus switch in an SC-70-5 package.

The 74CBT16800CDGVRE4 from Texas Instruments is a 10 x 1:1 bus switch Integrated Circuit in a 48-TVSOP package.

The 74CBT16209ADGGRG4 from Texas Instruments is a bus FET exchange switch with a 9 x 2:2 configuration, in a 48-TSSOP package.

The 74CBTLV16211CGRDR from Texas Instruments is a 12 x 1:1 bus switch in a 54-BGA Microstar Junior (8x5.5) package.

The 74CBTLV1G125DCKRG4 from Texas Instruments is a bus switch Integrated Circuit configured as 1 x 1:1 in an SC-70-5 package.

The 74CBTD16210DGVRE4 from Texas Instruments is a bus switch Integrated Circuit with a 10 x 1:1 configuration, in a 48-TVSOP package.

The 74CBTLV16211CZRDR from Texas Instruments is a 12 x 1:1 bus switch Integrated Circuit in a 54-BGA Microstar Junior (8x5.5) package.

The 74CBT16245DGVRG4 from Texas Instruments is an 8 x 1:1 bus switch Integrated Circuit in a 48-TVSOP package.

The 74CBTD3861DBQRG4 from Texas Instruments is a bus switch configured as 10 x 1:1 in a 24-SSOP package.

The 74CBT3305CDGKRG4 from Texas Instruments is a bus switch Integrated Circuit with 1 x 1:1 switch in an 8-VSSOP package.

The 74CBT16245DGGRE4 from Texas Instruments is a bus switch Integrated Circuit with 8 x 1:1 switches in a 48-TSSOP package.

The 74CBT16210DGGRE4 from Texas Instruments is a bus switch Integrated Circuit configured as 10 x 1:1 in a 48-TSSOP package.

74CBTLV16211GRG4 from Texas Instruments is a Integrated Circuit 6.5-pF, 3.3-V, 1:1 (SPST), 24-channel FET bus switch (SSOP, TSSOP, TVSOP packages) - Protocol & bus switches & muxes. The SN74CBTLV16211 provides 24 bits of high-speed bus switching. The low on-state resistance of the switch allows connections to be made with minimal propagation delay. The device is organized as dual 12-bit bus switches with separate output-enable (OE) inputs. It can be used as two 12-bit bus switches or as one 24-bit bus switch. When OE is low, the associated 12-bit bus switch is on, and port A is connected to port B. When OE is high, the switch is open, and the high-impedance state exists between the two ports. This device is fully specified for partial-power-down applications using I off. The I off feature ensures that damaging current will not backflow through the device when it is powered down. The device has isolation during power off. To ensure the high-impedance state during power up or power down, OE should be tied to V CC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.

The 74CBTLV3125PWRG4 from Texas Instruments is a bus switch Integrated Circuit with 1 x 1:1 configuration, in a 14-TSSOP package.

The 74CBTLV16210VRE4 from Texas Instruments is a 10 x 1:1 bus switch Integrated Circuit in a 48-TVSOP package.

The 74CBTLV16210GRG4 from Texas Instruments is a bus switch Integrated Circuit with 10 x 1:1 configuration, in a 48-TSSOP package.
