74CBTH16211DLRG4

Texas Instruments
Low stock

The 74CBTH16211DLRG4 from Texas Instruments is a bus switch Integrated Circuit with 12 x 1:1 channels, in a 56-SSOP package.

View full details

74CBTH16211DGVRE4

Texas Instruments
Low stock

The 74CBTH16211DGVRE4 from Texas Instruments is a bus switch Integrated Circuit configured as 12 x 1:1 in a 56-TVSOP package.

View full details

74CBTH16211DGVRG4

Texas Instruments
Low stock

The 74CBTH16211DGVRG4 from Texas Instruments is a bus switch Integrated Circuit with 12 x 1:1 switches in a 56-TVSOP package.

View full details

SN74CBTH16211DL

Texas Instruments
Low stock

The SN74CBTH16211DL from Texas Instruments is a bus switch Integrated Circuit with 12 x 1:1 switches, in a 56-SSOP package.

View full details

SN74CBTH16211DLR

Texas Instruments
Low stock

The SN74CBTH16211DLR from Texas Instruments is a 12 x 1:1 bus switch Integrated Circuit in a 56-SSOP package.

View full details

SN74CBTH16211DGVR

Texas Instruments
Low stock

The SN74CBTH16211DGVR from Texas Instruments is a bus switch with 12 x 1:1 configuration in a 56-TVSOP package.

View full details

SN74CBTH16211DGGR

Texas Instruments
In stock

SN74CBTH16211DGGR from Texas Instruments is a Integrated Circuit 5-V, 1:1 (SPST), 24-channel FET bus switch with bus hold - Protocol & bus switches & muxes. The SN74CBTH16211 provides 24 bits of high-speed TTL-compatible bus switching. The low on-state resistance of the switch allows connections to be made with minimal propagation delay. The device is organized as dual 12-bit bus switches with separate output-enable (OE) inputs. It can be used as two 12-bit bus switches or one 24-bit bus switch. When OE is low, the associated 12-bit bus switch is on, and the A port is connected to the B port. When OE is high, the switch is open, and a high-impedance state exists between the two ports. Active bus-hold circuitry is provided to hold unused or floating A and B ports at a valid logic level. To ensure the high-impedance state during power up or power down, OE should be tied to V CC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.

View full details
