Search results for “ADC12C”
Products
ADC12C105CISQX
Texas InstrumentsThe ADC12C105CISQX from Texas Instruments is a 12-bit analog-to-digital converter (ADC) with 1 input and pipelined architecture, in a 32-WQFN (5x5) package.
View full detailsADC12C080CISQ
Texas InstrumentsThe ADC12C080CISQ from Texas Instruments is a 12-bit pipelined analog-to-digital converter in a 32-WQFN package.
View full detailsADC12C170CISQ
National SemiconductorThe ADC12C170CISQ from National Semiconductor is a 12-bit analog-to-digital converter (ADC) with 1 input and 1 pipelined stage, in a 48-WQFN (7x7) package, using a proprietary method.
View full detailsADC12C105CISQ
Texas InstrumentsThe ADC12C105CISQ from Texas Instruments is a 12-bit pipelined analog-to-digital converter (ADC) with 1 input in a 32-WQFN (5x5) package.
View full detailsADC12C105CISQE/NOPB
National SemiconductorThe ADC12C105CISQE/NOPB from National Semiconductor is a 12-bit pipelined analog-to-digital converter (ADC) with 1 input and 1 pipelined stage, in a 32-WQFN (5x5) package.
View full detailsADC12C105CISQ/NOPB
Texas InstrumentsThe ADC12C105CISQ/NOPB from Texas Instruments is a 12-bit pipelined ADC with 1 input and 1 pipelined in a 32-WQFN (5x5) package.
View full detailsADC12C170CISQ/NOPB
National SemiconductorThe ADC12C170CISQ/NOPB from National Semiconductor is a 12-bit pipelined analog-to-digital converter (ADC) with 1 input and 1 pipelined stage, in a 48-WQFN (7x7) package.
View full detailsADC12C170CISQ/NOPB
Texas InstrumentsThe ADC12C170CISQ/NOPB from Texas Instruments is a 12-bit pipelined analog-to-digital converter with 1 input and 1 pipelined output, in a 48-WQFN (7x7) package.
View full detailsADC12C080CISQE/NOPB
Texas InstrumentsThe ADC12C080CISQE/NOPB from Texas Instruments is a 12-bit analog-to-digital converter (ADC) with 1 input and pipelined architecture, in a 32-WQFN (5x5) package.
View full detailsADC12C105CISQE
National SemiconductorThe ADC12C105CISQE from National Semiconductor is a 12-bit analog-to-digital converter with 1 input and pipelined architecture, in a 32-WQFN (5x5) package.
View full detailsADC12C080CISQ/NOPB
Texas InstrumentsThe ADC12C080CISQ/NOPB from Texas Instruments is a 12-bit pipelined analog-to-digital converter with 1 input, in a 32-WQFN (5x5) package.
View full detailsADC12C105CISQE/NOPB
Texas InstrumentsThe ADC12C105CISQE/NOPB from Texas Instruments is a 12-bit pipelined analog-to-digital converter with 1 input, in a 32-WQFN (5x5) package.
View full detailsADC12C105CISQ/NOPB
Texas InstrumentsADC12C105CISQ/NOPB from Texas Instruments is a Integrated Circuit 12-Bit, 105-MSPS, 1.0-GHz Input Bandwidth Analog-to-Digital Converter (ADC) - High-speed ADCs (≥10 MSPS). The ADC12C105 is a high-performance CMOS analog-to-digital converter capable of converting analog input signals into 12-bit digital words at rates up to 105 Mega Samples Per Second (MSPS). This converter uses a differential, pipelined architecture with digital error correction and an on-chip sample-and-hold circuit to minimize power consumption and the external component count, while providing excellent dynamic performance. A unique sample-and-hold stage yields a full-power bandwidth of 1 GHz. The ADC12C105 may be operated from a single +3.0V or +3.3V power supply and consumes low power. A separate +2.5V supply may be used for the digital output interface which allows lower power operation with reduced noise. A power-down feature reduces the power consumption to very low levels while still allowing fast wake-up time to full operation. The differential inputs accept a 2V full scale differential input swing. A stable 1.2V internal voltage reference is provided, or the ADC12C105 can be operated with an external 1.2V reference. Output data format (offset binary versus 2's complement) and duty cycle stabilizer are pin-selectable. The duty cycle stabilizer maintains performance over a wide range of clock duty cycles. The ADC12C105 is available in a 32-lead WQFN package and operates over the industrial temperature range of -40°C to +85°C.
View full details
