Search results for “iso774x”
Products
ISO7742FSDBQR
Texas InstrumentsISO7742FSDBQR from Texas Instruments is a Reinforced 4-channel, 2/2, digital isolator - Digital isolators. The ISO774x devices are high-performance, quad-channel digital isolators with 5000VRMS (DW package) and 3000VRMS (DBQ package) isolation ratings per UL 1577. This family includes devices with reinforced insulation ratings according to VDE, CSA, TUV and CQC. The ISO7741B device is designed for applications that require basic insulation ratings only. The ISO774x devices provide high electromagnetic immunity and low emissions at low power consumption, while isolating CMOS or LVCMOS digital I/Os. Each isolation channel has a logic input and output buffer separated by a double capacitive silicon dioxide (SiO2) insulation barrier. These devices come with enable pins which can be used to put the respective outputs in high impedance for multi-controller driving applications and to reduce power consumption. The ISO7740 device has all four channels in the same direction, the ISO7741 device has three forward and one reverse-direction channels, and theISO7742device has two forward and two reverse-direction channels. If the input power or signal is lost, default output is high for devices without suffix F and low for devices with suffix F. See the Device Functional Modes section for further details. Used in conjunction with isolated power supplies, these devices help prevent noise currents on data buses, such as RS-485, RS-232, and CAN, or other circuits from entering the local ground and interfering with or damaging sensitive circuitry. Through remarkable chip design and layout techniques, electromagnetic compatibility of the ISO774x devices significantly enhanced to ease system-level ESD, EFT, surge, and emissions compliance. The ISO774x devices are available in 16-pin SOIC and QSOP packages.
View full detailsISO7741FSDBQR
Texas InstrumentsISO7741FSDBQR from Texas Instruments is a Reinforced 4-channel, 3/1, digital isolator - Digital isolators. The ISO774x devices are high-performance, quad-channel digital isolators with 5000VRMS (DW package) and 3000VRMS (DBQ package) isolation ratings per UL 1577. This family includes devices with reinforced insulation ratings according to VDE, CSA, TUV and CQC. The ISO7741B device is designed for applications that require basic insulation ratings only. The ISO774x devices provide high electromagnetic immunity and low emissions at low power consumption, while isolating CMOS or LVCMOS digital I/Os. Each isolation channel has a logic input and output buffer separated by a double capacitive silicon dioxide (SiO2) insulation barrier. These devices come with enable pins which can be used to put the respective outputs in high impedance for multi-controller driving applications and to reduce power consumption. The ISO7740 device has all four channels in the same direction, the ISO7741 device has three forward and one reverse-direction channels, and theISO7742device has two forward and two reverse-direction channels. If the input power or signal is lost, default output is high for devices without suffix F and low for devices with suffix F. See the Device Functional Modes section for further details. Used in conjunction with isolated power supplies, these devices help prevent noise currents on data buses, such as RS-485, RS-232, and CAN, or other circuits from entering the local ground and interfering with or damaging sensitive circuitry. Through remarkable chip design and layout techniques, electromagnetic compatibility of the ISO774x devices significantly enhanced to ease system-level ESD, EFT, surge, and emissions compliance. The ISO774x devices are available in 16-pin SOIC and QSOP packages.
View full detailsISO7741FBDW
Texas InstrumentsThe ISO7741FBDW from Texas Instruments is a general-purpose enhanced basic digital isolator with 4 channels, rated 5000 Vrms, 100 Mbps and 85 kV/µs CMTI, in a 16-SOIC (0.295", 7.50 mm width) package.
View full detailsISO7741BDWR
Texas InstrumentsThe ISO7741BDWR from Texas Instruments is a general-purpose digital isolator rated 5000 Vrms with 4 channels, 100 Mbps data rate, 85 kV/µs CMTI, in a 16-SOIC package (0.295", 7.50 mm width).
View full detailsISO7741FSDBQ
Texas InstrumentsThe ISO7741FSDBQ from Texas Instruments is a digital isolator for CAN, RS232, RS485 and SPI with 4 channels, 3000 Vrms isolation, 100 Mbps, 85 kV/µs CMTI, in a 16-SSOP (0.154", 3.90 mm width) package.
View full detailsISO7741BDW
Texas InstrumentsThe ISO7741BDW from Texas Instruments is a general-purpose digital isolator rated 5000 Vrms with 4 channels, 100 Mbps data rate, 85 kV/µs CMTI, in a 16-SOIC package (0.295", 7.50 mm width).
View full detailsISO7742FSDBQ
Texas InstrumentsThe ISO7742FSDBQ from Texas Instruments is a digital isolator for CAN, RS232, RS485 and SPI with 4 channels, 3000 Vrms isolation, 100 Mbps, 85 kV/µs CMTI, in a 16-SSOP (0.154", 3.90 mm width) package.
View full detailsISO7741FBDWR
Texas InstrumentsThe ISO7741FBDWR from Texas Instruments is a digital isolator with enhanced basic isolation (MYNA).
View full details
