SN74ABTE16245DL from Texas Instruments is a Integrated Circuit 16-bit Incident-Wave Switching Bus Transceivers With 3-State Outputs - General-purpose transceivers. The ’ABTE16245 devices are 16-bit (dual-octal) noninverting 3-state transceivers designed for synchronous two-way communication between data buses. The control-function implementation minimizes external timing requirements. These devices can be used as two 8-bit transceivers or one 16-bit transceiver. They allow data transmission from the A bus to the B bus or from the B bus to the A bus, depending on the logic level at the direction-control (DIR) input. The output-enable (OE) input can be used to disable the device so that the buses are effectively isolated. When (OE) is low, the device is active. The B port has an equivalent 25- series output resistor to reduce ringing. Active bus-hold inputs also are on the B port to hold unused or floating inputs at a valid logic level. The A port provides for the precharging of the outputs via V CC BIAS, which establishes a voltage between 1.3 V and 1.7 V when V CC is not connected. Active bus-hold circuitry holds unused or undriven inputs at a valid logic state. Use of pullup or pulldown resistors with the bus-hold circuitry is not recommended.

SN74ABTE16246DLR from Texas Instruments is a Integrated Circuit 11-Bit Incident-Wave Switching Bus Transceivers With 3-State and Open-Collector Outputs - General-purpose transceivers. The SN74ABTE16246 is an 11-bit noninverting transceiver designed for asynchronous two-way communication between buses. This device has open-collector and 3-state outputs. The device allows data transmission from the A bus to the B bus or from the B bus to the A bus, depending on the logic level at the direction-control (DIR) input. The output-enable (OE) input can be used to disable the device so that the buses are effectively isolated. When OE is low, the device is active. The B port has an equivalent 25- series output resistor to reduce ringing. Active bus-hold inputs on the B port hold unused or floating inputs at a valid logic level. The A port provides for the precharging of the outputs via V CC BIAS, which establishes a voltage between 1.3 V and 1.7 V when V CC is not connected. Active bus-hold circuitry holds unused or undriven inputs at a valid logic state. Use of pullup or pulldown resistors with the bus-hold circuitry is not recommended.

SN74ABTE16245DLR from Texas Instruments is a Integrated Circuit 16-bit Incident-Wave Switching Bus Transceivers With 3-State Outputs - General-purpose transceivers. The ’ABTE16245 devices are 16-bit (dual-octal) noninverting 3-state transceivers designed for synchronous two-way communication between data buses. The control-function implementation minimizes external timing requirements. These devices can be used as two 8-bit transceivers or one 16-bit transceiver. They allow data transmission from the A bus to the B bus or from the B bus to the A bus, depending on the logic level at the direction-control (DIR) input. The output-enable (OE) input can be used to disable the device so that the buses are effectively isolated. When (OE) is low, the device is active. The B port has an equivalent 25- series output resistor to reduce ringing. Active bus-hold inputs also are on the B port to hold unused or floating inputs at a valid logic level. The A port provides for the precharging of the outputs via V CC BIAS, which establishes a voltage between 1.3 V and 1.7 V when V CC is not connected. Active bus-hold circuitry holds unused or undriven inputs at a valid logic state. Use of pullup or pulldown resistors with the bus-hold circuitry is not recommended.

74ABT16500CMTD from Fairchild Semiconductor is a BUS TRANSCEIVER, ABT SERIES

74ABT16501CSSCX from Fairchild Semiconductor is a BUS TRANSCEIVER, ABT SERIES

74ABT273CSJX from onsemi is a IC FF D-TYPE SNGL 8BIT 20SOP

74ABT00DB118 from NXP USA Inc. is a NOW NEXPERIA 74ABT00DB - NAND GA

74ABT74D/L112 from NXP USA Inc. is a D FLIP-FLOP, ABT SERIES

74ABT574CMSA from Fairchild Semiconductor is a IC FF D-TYPE SNGL 8BIT 20SSOP

74ABT273CSCX from Fairchild Semiconductor is a IC FF D-TYPE SNGL 8BIT 20SOIC

74ABT2244CSC from Fairchild Semiconductor is a IC BUFFER NON-INVERT 5.5V 20SOIC

74ABT16374CMTDX from Fairchild Semiconductor is a IC FF D-TYPE DUAL 8BIT 48TSSOP

74ABT374CSCX from onsemi is a IC FF D-TYPE SNGL 8BIT 20SOIC

74ABT16374CMTD from Fairchild Semiconductor is a IC FF D-TYPE DUAL 8BIT 48TSSOP

74ABT16374CSSCX from Fairchild Semiconductor is a IC FF D-TYPE DUAL 8BIT 48SSOP

74ABT245CSJ from Fairchild Semiconductor is a IC TXRX NON-INVERT 5.5V 20SOP

74ABT2244CMSA from Fairchild Semiconductor is a IC BUFFER NON-INVERT 5.5V 20SSOP

74ABT16500CSSCX from Fairchild Semiconductor is a BUS TRANSCEIVER, ABT SERIES

74ABT16374CSSC from Fairchild Semiconductor is a IC FF D-TYPE DUAL 8BIT 48SSOP

74ABT16652CSSC from Fairchild Semiconductor is a IC TXRX NON-INVERT 5.5V 56SSOP

SN74ABT16841DLR from Texas Instruments is a Integrated Circuit 20-Bit Bus-Interface D-Type Latches With 3-State Outputs - D-type latches. These 20-bit latches feature 3-state outputs designed specifically for driving highly capacitive or relatively low-impedance loads. They are particularly suitable for implementing buffer registers, I/O ports, bidirectional bus drivers, and working registers. The 'ABT16841 can be used as two 10-bit latches or one 20-bit latch. The 20 transparent D-type latches provide true data at the outputs. While the latch-enable (1LE or 2LE) input is high, the Q outputs of the corresponding 10-bit latch follow the D inputs. When LE is taken low, the Q outputs are latched at the levels set up at the D inputs. A buffered output-enable (1OE or 2OE) input can be used to place the outputs of the corresponding 10-bit latch in either a normal logic state (high or low logic levels) or a high-impedance state. In the high-impedance state, the outputs neither load nor drive the bus lines significantly. The output-enable input does not affect the internal operation of the latches. Old data can be retained or new data can be entered while the outputs are in the high-impedance state. When V CC is between 0 and 2.1 V, the device is in the high-impedance state during power up or power down. However, to ensure the high-impedance state above 2.1 V, OE should be tied to V CC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver. The SN54ABT16841 is characterized for operation over the full military temperature range of -55°C to 125°C. The SN74ABT16841 is characterized for operation from -40°C to 85°C.

74ABT2244CSJ from Fairchild Semiconductor is a IC BUFFER NON-INVERT 5.5V 20SOP

74ABT16373CMTDX from Fairchild Semiconductor is a BUS DRIVER, ABT SERIES

74ABT273CMTCX from Fairchild Semiconductor is a IC FF D-TYPE SNGL 8BIT 20TSSOP

SN74ABT18504PM from Texas Instruments is a IC SCAN-TEST-DEV/TXRX 64-LQFP

74ABT244CSJX from Fairchild Semiconductor is a IC BUFFER NON-INVERT 5.5V 20SOP

SN74ABT640DBR from Texas Instruments is a Integrated Circuit Octal Bus Transceivers With 3-State Outputs - General-purpose transceivers. The 'ABT640 bus transceivers are designed for asynchronous communication between data buses. These devices transmit inverted data from the A bus to the B bus or from the B bus to the A bus, depending on the level at the direction-control (DIR) input. The output-enable () input can be used to disable the device so that the buses are effectively isolated. To ensure the high-impedance state during power up or power down, should be tied to V CC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver. The SN54ABT640 is characterized for operation over the full military temperature range of -55°C to 125°C. The SN74ABT640 is characterized for operation from -40°C to 85°C.

74ABT16646CMTDX from onsemi is a IC TXRX NON-INVERT 5.5V 56TSSOP

74ABT541CMSAX from Fairchild Semiconductor is a IC BUFFER NON-INVERT 5.5V 20SSOP

74ABT646ADB,118 from NXP USA Inc. is a IC TXRX NON-INVERT 5.5V 24SSOP

SN74ABT16501DLR from Texas Instruments is a Integrated Circuit 18-bit universal bus transceivers with 3-state outputs - General-purpose transceivers. These 18-bit universal bus transceivers consist of storage elements that can operate either as D-type latches or D-type flip-flops to allow data flow in transparent or clocked modes. Data flow in each direction is controlled by output-enable (OEAB and), latch-enable (LEAB and LEBA), and clock (CLKAB and CLKBA) inputs. For A-to-B data flow, the device operates in the transparent mode when LEAB is high. When LEAB is low, the A data is latched if CLKAB is held at a high or low logic level. If LEAB is low, the A data is stored in the latch/flip-flop on the low-to-high transition of CLKAB. When OEAB is high, the outputs are active. When OEAB is low, the outputs are in the high-impedance state. Data flow for B to A is similar to that of A to B but uses, LEBA, and CLKBA. The output enables are complementary (OEAB is active high and is active low). To ensure the high-impedance state during power up or power down, OE should be tied to GND through a pulldown resistor and should be tied to V CC through a pullup resistor; the minimum value of the resistor is determined by the current-sourcing/current-sinking capability of the driver. The SN54ABT16501 is characterized for operation over the full military temperature range of -55°C to 125°C. The SN74ABT16501 is characterized for operation from -40°C to 85°C.

74ABT543ADB,118 from NXP USA Inc. is a IC TXRX NON-INVERT 5.5V 24SSOP

74ABT2244CSCX from Fairchild Semiconductor is a IC BUFFER NON-INVERT 5.5V 20SOIC

74ABT240CSC from Fairchild Semiconductor is a IC BUFFER INVERT 5.5V 20SOIC
